6×36 steel Wire Rope is a type of steel wire rope with an individual wire rope core. It has 6 strands of 36 wires in each strand, which together form an extremely strong and flexible rope. The individual wires in the strands are generally uncoated, making the rope more pliable and durable.
| Size Mm | Quantity | Sku | |
|---|---|---|---|
| 8 mm | |||
| 9 mm | |||
| 10 mm | |||
| 11 mm | |||
| 12 mm | |||
| 13 mm | |||
| 14 mm | |||
| 16 mm | |||
| 18 mm | |||
| 19 mm | |||
| 20 mm | |||
| 22 mm | |||
| 24 mm | |||
| 25 mm | |||
| 28 mm | |||
| 32 mm | |||
| 36 mm | |||
| 38 mm | |||
| 40 mm | |||
| 44 mm | |||
| 46 mm | |||
| 48 mm | |||
| 52 mm | |||
| 56 mm | |||
| 58 mm | |||
| 60 mm | |||
| 76 mm | |||
| 80 mm |
Wire rope as a wire rope manufacturer, specializes in the production of 6×36 steel wire ropes, offering top-quality products that meet the highest standards of design and performance. With a special emphasis on safety, our 6×36 wire ropes feature a highly flexible and wear-resistant 6×36 configuration that is designed to be used in extreme conditions in order to strengthen applications and maximize operator efficiency. Constructed from premium steel core construction, the latest designs of our 6×36 also include added corrosion resistance and additional strength.
| Rope Diameter (mm) | Approx. Mass (kg/100m) | 1570 N/mm² (kN) | 1770 N/mm² (kN) | 1960 N/mm² (kN) |
|---|---|---|---|---|
| 8 | 26.8 | 36 | 41 | 45 |
| 9 | 33.8 | 45 | 52 | 57 |
| 10 | 41.8 | 56 | 63 | 70 |
| 11 | 50.6 | 68 | 76 | 85 |
| 12 | 60.2 | 81 | 90 | 101 |
| 13 | 70.7 | 95 | 107 | 118 |
| 14 | 82.0 | 109 | 124 | 137 |
| 16 | 107.0 | 143 | 161 | 179 |
| 18 | 135 | 181 | 204 | 226 |
| 19 | 153 | 192 | 216 | 240 |
| 20 | 167 | 221 | 252 | 279 |
| 22 | 202 | 271 | 304 | 338 |
| 24 | 241 | 322 | 363 | 402 |
| 25 | 262 | 349 | 394 | 436 |
| 28 | 328 | 438 | 493 | 548 |
| 32 | 428 | 571 | 644 | 715 |
| 36 | 542 | 724 | 816 | 905 |
| 38 | 604 | 808 | 911 | 1008 |
| 40 | 669 | 894 | 1009 | 1117 |
| 44 | 810 | 1080 | 1220 | 1352 |
| 46 | 885 | 1184 | 1334 | 1478 |
| 48 | 964 | 1290 | 1450 | 1609 |
| 52 | 1130 | 1510 | 1710 | 1888 |
| 56 | 1310 | 1750 | 1980 | 2190 |
| 58 | 1405 | 1877 | 2124 | 2349 |
| 60 | 1506 | 2014 | 2270 | 2514 |
| 76 | 2415 | 3231 | 3643 | 4034 |
| 80 | 2675 | 3580 | 4036 | 4460 |
| Size (MM) | 8 mm, 9 mm, 10 mm, 11 mm, 12 mm, 13 mm, 14 mm, 16 mm, 18 mm, 19 mm, 20 mm, 22 mm, 24 mm, 25 mm, 28 mm, 32 mm, 36 mm, 38 mm, 40 mm, 44 mm, 46 mm, 48 mm, 52 mm, 56 mm, 58 mm, 60 mm, 76 mm, 80 mm |
|---|
