Concrete Lifting Loop

Our Concrete Lifting Loop is a specialized device used in the construction industry to facilitate the lifting and handling of concrete elements, such as precast concrete panels and blocks. These loops are typically made of high-strength materials, like steel wire or synthetic materials, and are embedded or attached to the concrete during the casting process. They provide a secure attachment point for cranes or lifting equipment to hoist and transport the concrete elements safely and efficiently. Our Concrete lifting loops play a crucial role in construction projects, ensuring heavy concrete components’ precise and secure positioning. They are designed to meet stringent safety and load-bearing standards to prevent accidents during material handling.

Add to Quote
Size Data Sheet

Description

Industrial Concrete Lifting Loop

SSTC offers a heavy-duty Lifting Loop. The Lifting must be screwed into the socket completely. You may need to clean the concrete residue in the thread of the lifting anchor by means of thread cleaner.

Key Features:

  1. Galvanized steel wire  (DIN EN 12385-4)
  2. The wire rope is made of a special zinc solid steel wire rope
  3. The thread is made of bright precision steel.
  4. Fits for application with all thread system anchors like Cast-in Concrete Inserts, Waved end lifting anchors etc.
  5. WLL, ID number, and JBL is marked on the tag.

Specifications:

concrete lifting loop 3
ItemCode(s) Thread Finished WLL 0 to 45o Dimensions
D e h
Tonne mm mm mm
LPRD12 Rd 12 0.5 12 20 155
LPRD14 Rd 14 0.8 14 22 155
LPRD16 Rd 16 1.2 16 23 155
LPRD18 Rd 18 1.6 18 28 190
LPRD20 Rd 20 2 20 30 215
LPRD24 Rd 24 2.5 24 34 255
LPRD30 Rd 30 4 30 47 300
LPRD36 Rd 36 6.3 36 55 340
LPRD42 Rd 42 8 42 61 425
LPRD52 Rd 52 12.5 52 79 550

Additional information

Size (Tonne)

0.5T, 0.8T, 1.2T, 1.6T, 2T, 2.5T, 4T, 6.3T, 8T, 12.5T
